BeB Control unit for rolling shutters with multi-frequency receiver compatible with radio controls from 433 to 868 MHz or 433.92 MHz, fixed code and rolling code

Specifications:
- Power supply: 230 Vac ± 10% 50-60 Hz
- Max motor power: 1.4 HP - 1000 W
- Control voltage: 12 Vdc - 500 mA max
- Flashing light: 230 Vac - 40 W max
- Working time: 3 - 30 sec. programmable
- Automatic closing: 0 - 240 sec. programmable
- Radio module: 433 to 868 MHz or 433.92 MHz (fixed codes and rolling codes)
- Dimensions (WxHxD): 95x145x50mm
- Weight: 350gr
- Degree of protection: IP56
- Italian product.

Features:
- Control unit designed to control shutters, awnings, roller shutters, transom windows, etc.
- Shutter maneuver times and waiting time for automatic re-closing are defined during the learning phase.
- Automatic reclosing functions, opening only command and AUX auxiliary relay.
- Bistable, pulse, minute timer, second timer modes.
- Central status signaling via LED.
- Common entrances.
- Step-by-step input, safety and STOP command.
